Akuvox - R26CF IP Door Intercom Unit with 1 Call Button (Video & Card reader) incl. Flush Mount Backbox
The Akuvox R26CF SIP IP Video Doorphone is a modern designed IP Door Intercom station featuring single call button, RFID card reader, colour camera and integrated microphone.
The Akuvox R26CF Intercom is an IP-connected device which uses high-grade materials and high quality construction to provide one-to-one audio and video communication between resident and visitor, together with access control to the building via connected door lock systems.
This unit also features bright blue LED icon indicators for function confirmation both in daylight and at night.
The R26CF is supplied including a flush-mount back box.
Interface Features
• 1xRJ45 10/100M Mbps Ethernet port
• Output relay: 2 relays for door opener
• Relays controlled individually by DTMF tones
• RS485 port
SIP Features
• SIP v1 (RFC2543), SIP v2 (RFC3261)
• Line: 2 SIP accounts
Audio Features
• 1 built-in microphone with IP67 rating
• 2W speaker with IP66 rating
• Codec: G.711a, G.711μ, G.722 and G.729
• Speech quality: 7 kHz
• Echo cancellation
• Voice activity detection
• Comfort noise generator
Video Features
• Resolution: up to 720p
• Image transfer rate: 720p@30fps max.
• Camera permanently operational
• Auto-night mode with LED illumination
• Illumination: 0.1LUX min.
• Auto white balance
• Internal light sensor: image lighting during dark hours
• Codec: H.264, MPEG-4 and MJPEG
• Support live stream and RTSP
• Compliance with ONVIF
Network Features
• Static IP or DHCP
• 802.1Q VLAN
• NTP for auto time setting
Administration Features
• Auto-provisioning: FTP/TFTP/HTTP/HTTPS/PnP/DHCP
• Configuration management: web-based management or auto provisioning
• TR069
• SNMP
Application Scenarios
• Office door phone with on-site or hosted IP-PBX
• Perfect for villa intercom with door access control
• Control remote site entry over the internet
- Premium audio and video quality
- Real-time entrance monitoring
- Remote door opening
- RFID card reader: Supports 13.56MHz access card
- SIP/ONVIF/PoE/IP65
- 120° wide-angle 3MP camera with automatic lighting
- Vandal resistant all-aluminium body
- Single Call Button
- Flush Mount (Back box included)
- Enclosure rating IP65
- Camera 3M pixels, with automatic lighting
- Button 1 call button
- RF Card Reader 13.56MHz
- PoE IEEE802.3af
- Safety G-sensor for tamper alarm
- Power Consumption 12v DC input, less than 12W
- Installation Flush Mount (Back box included)
- Body Material Aluminum panel
- Dimensions 190(H) x 110(W) x 35(D) mm
- Weight (Net) 1.05kg
- Weight (Gross) 0.80kg
